KEY PERFORMANCE FACTORS
Low Center of Gravity Playful Trail Bike
Sloping "low slung" front triangle design provides a low center of gravity & plenty of knee clearance for technical maneuvering and countersink control in deep conditions.
Maximum Heel Clearance with Low Q-Factor
With a heavily swaged rear triangle including dropouts, seatstays and chainstays, this versatile design allows even warmest of riding boots to be worn, while the narrow Q-Factor crank provides a more natural feeling cycling experience.
Adjustable Wheelbase and Tire Size Flexibility
The horizontal adjustable drop out system allows for /- 15mm rear center length adjustment and tire sizing up 27.5 X 4.5” for maximum floatation to dial in stability & playful handling.
WHY WE LOVE IT
This 29er has cross-country geometry designed specifically for women with a lightweight frame with a PowerCore bottom bracket for ideal pedaling efficiency to conquer those serious climbs. Pique 29 offers 100 mm of front and rear travel, tuned for women and on the leading Maestro Suspension Technology. Complete with a dropper post, the Pique 29 is built for cross-country racers and riders alike. The integrated design accommodates downtube water bottles on all size frames, XS-L. Built with a lightweight ALUXX SL-Grade aluminum frame, the Pique 29 offers a premium ride at a winning price. The 29-inch wheels ensure bike handling is stable and fast, boasts itself to precision cornering and bump-reducing qualities.
ALUXX SL ALUMINUM TECHNOLOGY
This High-Performance level, state-of-the-art aluminum material is made predominantly from 6011 alloy and delivers best-in-class strength-to-weight ratios. These framesets also feature unique welding technologies for a high-performance ride quality.
Sizes: S, M, L, XL
Colors: Gloss Gunmetal Black/Matte Black
Frame: ALUXX SL-Grade Aluminum, horizontal dropouts
Fork: Advanced-Grade Composite, alloy steerer, 15x150, low-rider rack mounts, extra water bottle mounts, disc
Shock: N/A
Handlebar: Giant Connect Trail, 31.8
Stem: Giant Contact
Seatpost: Giant Connect, 30.9
Saddle: Giant Sport
Pedals: N/A
Shifters: Shimano Deore
Front Derailleur: N/A
Rear Derailleur: Shimano Deore, Shadow
Brakes: SRAM Level hydraulic (F:180mm, R:160mm)
Brake Levers: SRAM Level T
Cassette: Shimano HG500, 12-speed, 10x51
Chain: Shimano
Crankset: ProWheel MPX, 28t
Bottom Bracket: ProWheel, press fit
Rims: Giant FB 27.5 wheelset, alloy, 86mm inner, AV & PV ready
Hubs: Giant Performance Tracker [F] 15x150mm sealed bearing [R] 12x197mm sealed bearing
Spokes: Stainless
Tires: Maxxis Colossus 27.5x4.5, foldable, TR,
Weight: The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
-
- S 5’4” - 5’8”
-
- M 5’7” - 5’11”
-
- L 5’10” - 6’2”
-
- XL 6’2” - 6’6”
| S | M | L | XL | ||
|---|---|---|---|---|---|
| LOW | HIGH | LOW | HIGH | LOW | HIGH | LOW | HIGH | ||
| A | SEAT TUBE LENGTH (inch) | 15 | 17 | 19 | 21 |
| B | SEAT TUBE ANGLE | 73.0° | 73.0° | 73.0° | 73.0° |
| C | TOP TUBE LENGTH (inch) | 23 | 23.8 | 24.6 | 25.4 |
| D | HEAD TUBE LENGTH (inch) | 3.9 | 4.5 | 5.1 | 5.9 |
| E | HEAD TUBE ANGLE | 68.5° | 68.5° | 68.5° | 68.5° |
| F | FORK RAKE (inch) | 2.4 | 2.4 | 2.4 | 2.4 |
| G | TRAIL (inch) | 3.5 | 3.5 | 3.5 | 3.5 |
| H | WHEELBASE (inch) | 44.4 | 45.2 | 46.1 | 46.9 |
| I | CHAIN STAY LENGTH (inch) | 17.5 | 18.1 | 17.5 | 18.1 | 17.5 | 18.1 | 17.5 | 18.1 |
| J | BOTTOM BRACKET DROP (inch) | 3 | 3 | 3 | 3 |
| K | STACK (inch) | 24.4 | 25 | 25.6 | 26.3 |
| L | REACH (inch) | 15.6 | 16.1 | 16.8 | 17.3 |
| M | STAND OVER HEIGHT (inch) | 28.3 | 28.9 | 30.4 | 31.9 |
| N | HANDLEBAR WIDTH (inch) | 30.7 | 30.7 | 30.7 | 30.7 |
| O | STEM LENGTH (inch) | 2 | 2 | 2.4 | 2.8 |
| P | CRANK LENGTH (inch) | 6.7 | 6.7 | 6.9 | 6.9 |
| Q | WHEEL SIZE | 27.5 | 27.5 | 27.5 | 27.5 |
Note: In Store Pick Up Only
